Wall-Mounted Enclosures

Gland Plate With Cable-Entry Frame and Cable Inserts

Perforated metal cable tray with pass-through frame.

Product introduction

Perforated cable tray with pass-through frame.

Information For download

Product line name	Cable tray with pass-through frame and optional inserts
Dimensions	120x58 mm, 8 positions for grommets ID-W-CExx
Material	Tray: coated steel sheet Grommets: elastomer, UL-94 Vo, self-extinguishing Pass-through frame: polyamide, UL-94 Vo, self-extinguishing
IP rating	IP54
Assembly/Installation	Into a cutout in the bottom of the cabinet instead of a full-scale cable tray
Technical information	Number of cables: See specific grommets ID-W-CExx
